Oil Heat-conducting Machine || EVA & Rubber Sheet Making Machines

EVA & Rubber Sheet Making Machines

sr-eva-h01

The heat-conducting oil furnace is a "low pressure and high temperature" type of high-efficiency energy-saving heating equipment.
A higher working temperature (≤340°C) can be obtained at a lower working pressure (<0.5MPa). When the heating temperature is 300°C, the operating pressure is only one-seventh of the saturated vapor pressure of water .
Closed circuit heating, high thermal efficiency (>95%).
It can be heated stably and evenly, and can achieve precise temperature control (temperature control accuracy can be within ±1℃).
With advanced and complete control system and safety monitoring device.
The heat transfer medium of the heating system is an organic heat carrier-heat transfer oil, which is odorless, non-toxic, non- environmental, has no effect on the health of the operators, has no corrosion to the equipment, and has a long service life.
The heat-conducting oil furnace can be installed horizontally near the thermal user (using thermal equipment or thermal environment), without laying foundations.

Model	Heating Power	Oil Capacity	Dimension	Oil Pump Flow Lift Power	Machine Weight	Expansion Tank
SR-EVA-H10	10KW	15 L	1100x500x1000	6 \| 27 \| 1.5	200 KG	100
SR-EVA-H18	18KW	23 L	1600x500x1250	6 \| 27 \| 1.5	200 KG	130
SR-EVA-H24	24KW	28 L	1950x650x1450	12.5 \| 30 \| 3	350 KG	150
SR-EVA-H36	36KW	48 L	1950x650x1450	12.5 \| 30 \| 3	350 KG	200
SR-EVA-H48	48KW	48 L	1950x650x1450	18 \| 40 \| 5.5	350 KG	230
SR-EVA-H60	60KW	52 L	1950x650x1450	18 \| 40 \| 5.5	350 KG	230
SR-EVA-H70	70KW	60 L	2150x700x1750	30 \| 48 \| 7.5	550 KG	280
SR-EVA-H90	90KW	68 L	2150x700x1750	30 \| 48 \| 7.5	550 KG	280
SR-EVA-H120	120KW	105 L	2200x700x1880	30 \| 48 \| 7.5	750 KG	300
SR-EVA-H150	150KW	195 L	2200x900x1880	30 \| 48 \| 7.5	750 KG	300
SR-EVA-H180	180KW	230 L	2200x1000x1880	45 \| 48 \| 11	1200 KG	320
SR-EVA-H240	240KW	260 L	2300x1000x1950	80 \| 38 \| 15	1200 KG	350
SR-EVA-H300	300KW	358 L	2800x1200x2000	45 \| 48 \| 11	1750 KG	450
SR-EVA-H500	500KW	510 L	2800x1500x2000	80 \| 38 \| 15	1850 KG	550
SR-EVA-H600	600KW	562 L	3000x1800x2150	80 \| 38 \| 15	1950 KG	600
SR-EVA-H700	700KW	638 L	3000x1800x2150	80 \| 38 \| 15	2200 KG	650
SR-EVA-H1400	1400KW	2100 L	3600x2900x2150	80 \| 85 \| 15	6500 KG	1200
